Extensive cargo terminals network
Tankpartners partners with terminals in major ports of the world, trained in tankcontainers cleaning and maintenance.
From cargo terminals to your business
Tankpartners administers all shipping, return to port, reserve square, output control and the ship's arrival
Chemicals and Foods
Isotank for liquid cargoes
for chemical, food grade
and alcoholics transportation.
Gases
Isotanks certificateds for liquefied transport with great resistance to pressure gases and global network for cleaning and maintenance.
Tankpartners, the best solution for liquid cargoes shipping in tank containers
It doesn't matter where in the Brazil is your product, or where you need to send it to. When you need logistic solutions for liquids or gases, your best option is Tankpartners, tank container operator since 1992.
For Iso tanks leasing Tankpartners partnered exclusively with Trifleet, founded in 1990, and with offices in several European and Asian countries. Trifleet is specialized in iso tanks leasing, with more than 10 thousand units in its fleet, both targeted for multimodal transport and food storage, chemical or gaseous products.
With extensive industry expertise, Tankpartners has as market distinction, both by offering the iso tanks leasing and the complete logistics operation for this equipment. And more, the company ensures the full integrity of all its tanks for transport or storage of liquid products such as foods, agricultural chemicals, pharmaceutical or any other kind of product allowed in an isotank.
Tankpartners and its partners have a wide network of offices and terminals in several countries to meet demands outside of Brazil for safe and reliable shipping solutions for liquid cargoes of any type (*).
(*) submit the MSDS of you product in order that we can evaluate the best option in tank containers for you.
Leasing - Isotank rent (no buying option)
Photos
Mauris sit amet tortor.3
Mauris sit amet tortor.2
Mauris sit amet tortor.3
Mauris sit amet tortor.4
Mauris sit amet tortor.5
Mauris sit amet tortor.6
Mauris sit amet tortor.7
Mauris sit amet tortor.8
Mauris sit amet tortor.11
1 - 9
<
>
Primarily intended for chemical, gas and liquid products storage and transportation mode, the isotank is one of the safest and most practical solutions available worldwide. Tankpartners, through Trifleet equipment availability, offers isotanks by leasing them - equipment renting with no buy out option - and ensures tanks are only delivered at their full tank integrity.
The isotank equipment is a very flexible solution for companies looking for temporary storage increase and / or long term ones. This solution might eliminate the need of building tank farms at potential customers’ plants, saving exponentially in costs, flexibility, and in space requirement. Excellent cost x benefit solution for integrated logistics process and storage.
Iso tank operation - shipping liquid cargoes
As iso containers operator, Tankpartners is fully qualified to undertake the products' transport management at your business process - from the factory to the port, managing the ships' loading, managing reservations with ship owners and operators, port department and arrival control and, if applicable, providing door delivery to the final destination required by the customer.
Contact Tankpartners before boarding your next liquid cargo. We can help your company with domestic and international demands. We have stock facilities strategically allocated in several countries and in our local main facility at Santos port surroundings in Brazil, the largest port in Latin America, and among the 50 largest in the world.
Wide range of logistics solutions
Tankpartners - The isotank and the integrated transport process
The company looking for Tankpartners services is sure to find the best solution and the most comprehensive logistics services to meet their needs - from isotank leasing (*) to the complete isotank logistic process.
(*) consult us for building up a fleet for temporary use – minimum 12 months.
(**) consult us for emergencies.
Contact Tankpartners team before choosing your next partner in isotanks and boarding your next liquid cargo. We can help your company with domestic and international shipment of your products, as much as for liquid and gases storage.
(*) save tremendously by renting (leasing without buying option) our isotanks for temporary storage needs.
We have stock facilities strategically allocated in several countries and in the our main facilities in Brazil, located at the Port of Santos, the largest port in Latin America positioned among the top 50 in the world.
Technical Specifications
Isotanks with various specifications for transporting liquid and gas cargoes.
It doesn't matter where in the Brazil is your product, or where you need to send it to. When you need logistic solutions for liquids or gases, your best option is Tankpartners, tank container operator since 1992 and exclusive partner in the country for two of the largest multinational companies in the market segment
Check out below some types of iso tanks available in our inventory. Don't hesitate to contact us before transporting your product.
IMO Type 1 frame tank
TANK CONTAINER SPECIFICATION - IMO TYPE 1 FRAME TANK
Type: IMO type single compartment
Insulated and steam heated tank container
Dimensions: mm ft in Length 6,058 20 0 Width 2,438 8 0 Height 2,591 8 6
Capacites: 17,000 litre 4,622 US gallons 21,000 litre 5,547 US gallons 23,000 6,075 US gallons 24,000 litre 6,340 US gallons 25,000 6,790 US gallons 26,000 7,070 US gallons
Weights: Kgs Lbs Maximum gross from 30,480 to 36,000 from 67,196 to 79,365 Tare from 3,800 to 4,200 from 8,377 to 9,259
Pressures: Bar Psi Working pressure 4.0 58.0 Teste pressure 6.0 87.0 Steam operating pressure 4.0 58.0 Design pressure @ 130 6.0 87.0 Steam test pressure 6.0 87.0 Relief Valve 4.4 64.0
Shell material: Stainless steel, 316 A240. MDT 93 - 120 Cº
Code: ASME VIII, division 1 where applicable
Temperatures Cº Fº Maximum cargo temperature 120 248
Approvals: Construction Certicate (Lloyd's/ B.V./A.B.S.), UIC, CSC, TIR, IMO1, ISO, UK & US (DOT), RID/ADR, TC, AAR600, FRA
Standard fittings: Manlid 500 mm (20") diameter, 8 point (fore and aft) SWR (Sweet White Rubber)/PTFE 20% centimetre Dipstick Relief Valve One/ two 2.5" with flame proof gauze. Bursting disc provision. Manometer provision Air Inlet Valve 1.5" s/s Ball Valve With 1.5" B.S.P. connection. Manometer provision Top discharge 3" s/s Port and Blank Flanges. Syphon Pipe provision Spillboxes Two off. with no covers. Stainless steel internal tubes Bottom discharge 3" s/s cleanflow footvalve. 3" s/s Butterfly Valve. 3" s/s Flanged Outlet with Bland Flange or 3" B.S.P. Remote Trip. Fusible link provision. Insulation 45mm Glasswool/polyurethane with Marine Grade White Aluminum cladding Steam Heating 8 elements, 127mm wide, connected to centre ring Area - 8m2.3/4" B.S,P, wwith Plastic Caps Thermometer Fitted. Analog (contact type) in C and F.
Specification subject to change.
Detailed specification and drawings available on request
IMO Type 1 beam tank
TANK CONTAINER SPECIFICATION - IMO TYPE 1 BEAM TANK
Type: IMO type single compartment
Insulated and steam heated tank container
Dimensions: mm ft in Length 6,058 20 0 Width 6,438 8 0 Height 2,591 8 6
Capacity: 24,000 litre 6,340 US gallons 25,000 litre 6,604 US gallons 21,000 5,547 US gallons
Weights: Kgs Lbs Maximum gross 36,000 79,365 Tare from 3,620 to 4,220 from 7,984 to 9,308
Pressures: Bar Psi Working pressure 4.0 58.0 Teste pressure 6.0 87.0 Steam operating pressure 4.0 58.0 Design pressure @ 130 6.0 87.0 Steam test pressure 6.0 87.0 Relief Valve 4.4 64.0
Shell material: Stainless steel, 316 A240. MDT. 120 Cº
Code: ASME VIII, where applicable
Temperatures Cº Fº Maximum cargo temperature 120 248
Approvals: Construction Certificate (Lloyd's/ B.V./A.B.S.), UIC, CSC, TIR, IMO1, ISO, UK & US (DOT), RID/ADR, TC, AAR600, FRA
Standard fittings: Manlid 500 mm (20") diameter, 8 closure (fore and aft) SWR (Sweet White Rubber)/PTFE Relief Valve One/ two 2.5" Safety Relief Valves with flame proof gauze. Rupture disc provision. Manometer quarter inch BSP provision. Air Inlet Valve 1.5" Black Ball Valve with Manometer provision Top discharge 3" s/s Port and Blank Flanges. Syphon tube provision Spillboxes Two off, with no covers. External/ internal Stainless steel drain tubes. Bottom discharge 3" s/s Footvalve. 3" s/s Butterfly Valve. 3" s/s B.S.P. and Cap Remote Tripe.
Fusible Link Provision.Insulation 50mm (2") rigid polyisocuyanurate foam over tank shell, compressed mineral wool over steam pan area, clad in Marine Grade White Aluminum Steam Heating 7 elements welded to external underside giving 8m2 coverage. 3/4" B.S.P. with Plastic caps Thermometer Fitted. Analog in C and F.
Specification subject to change.
Detailed specification and drawings available on request.
With personalized customer services, Tankpartners meets all the liquid and gases logistic needs of its customers.
When our customers need to ship liquid cargos in Brazil or internationally they always find in Tankpartners a real and qualified partner to meet their transportation needs. With personalized customer service, Tankpartners is attentive to what its customer really needs, from Iso tanks leasing to custom built containers, or the complete process of cargo transportation.
In addition to providing iso tanks with various specifications, Tankpartners also manage all the transportation process from the origin to the destination - door to door, pier to pier, door to pier or pier to door - always selecting providers with best cost / benefit services available at that time.
From the time the cargo is manufactured or the customer arrives at the pier for shipment, our customers are systematically informed of everything that happens until the product delivery at the given destination in Brazil or abroad.
